Easily accessible and lockable illumination dial is located on the left side of turret housing. Features eleven intensity levels of illumination with off positions between each setting.
- APO System
- Optically Indexed Lenses
- HD Lens Elements
- Fully Multi-Coated
- Plasma Tech
- First Focal Plane Reticle. Glass-Etched Reticle. Illuminated Reticle.
- Waterproof. Fogproof. Shockproof.
- Single-Piece Tube
- Aircraft-Grade Aluminum
- Hard Anodized Stealth Shadow Finish
- L-Tec Turrets
- External Rotation Indicator
- Locking Illumination.
- Side Focus
- L-Tec Zero Stop
- Maximized Turret Zero Adjustment
- Micro Adjust Zero Setting
- Friction Reduction System
- Erector Tube System.
- Fast Focus Eyepiece
- Locking Side Illumination
- Magnification 4.5-27x
- Objective Lens Diameter 56 mm
- Eye Relief 3.7 inches
- Field of View 25.3-4.4 ft/100 yds
- Tube Size 34 mm
- Turret Style L-Tec
- Adjustment Graduation .1 MRAD
- Travel Per Rotation 10 MRAD
- Max Elevation Adjustment 33 MRAD
- Max Windage Adjustment 14 MRAD
- Parallax Setting 32 yards to infinity
- Length 14.4 inches
- Weight 48.5 oz
Index-matched lenses correct color across the entire visual spectrum.
Optically Indexed Lenses
Optimize image sharpness and brightness from edge to edge.
HD Lens Elements
Premium extra-low dispersion glass delivers the ultimate in resolution and color fidelity, resulting in high-definition images.
Ultimate anti-reflective coatings on all air-to-glass surfaces provide maximum light transmission for peak clarity and the pinnacle of low-light performance.
Integrated locking mechanism prevents accidental adjustments. Turrets provide fast, accurate, easily read elevation and windage adjustments.
External Rotation Indicator
Provides quick visual and tactile reference of elevation turret’s rotational position.
Locks illumination at preferred setting.
L-Tec Zero Stop
Prevents elevation turret from dialing below sight in range using rugged steel components. Internal mechanisms stay free of sand, dirt, dust, moisture and other foreign materials—even when setting the zero-stop position.
Maximized Turret Zero Adjustment
Turret design allows expanded adjustment range when L-Tec zero stop feature is disengaged for zeroing purposes.
Micro Adjust Zero Setting
Infinite zero setting positions allow zero to be set between clicks for optimal accuracy.
Friction Reduction System
Heat-treated, hardened-steel pad floats on turret screw’s end, linking with hardened steel ring on erector tube for steel-on-steel contact. Prevents galling or deformation of contact point for superb durability and repeatability.
Erector Tube System
Precision-machined from aircraft grade aluminum with anti-galling properties for a lighter weight, strong, durable tube. Stainless Steel offset coil spring erector biasing system withstands much higher stresses than traditional flat erector springs and al
